- Hitch Weight
- 1,330 lb.
- 11,000 lb.
- 9,409 lb.
- 1,591 lb.
- Exterior Length
- 40' 11"
- Exterior Height
- 11' 8"
- Exterior Width
- Fresh Water
- 44 gal.
- Gray Water
- 80 gal.
- Black Water
- 30 gal.
- Awning Size
- 15' (opt)
GVWR (Gross Vehicle Weight Rating) – is the maximum permissible weight of the unit when fully loaded. It includes all weights, inclusive of all fluids, cargo, optional equipment and accessories. For safety and product performance do NOT exceed the GVWR.
GCWR (Gross Combined Weight Rating) – is the maximum permissible loaded weight of your motor home and any towed trailer or towed vehicle. Actual GCWR of this vehicle may be limited by the sum of the GVWR and the installed hitch receiver maximum capacity rating; see hitch rating label for detail.
GAWR (Gross Axle Weight Rating) – is the maximum permissible weight, including cargo, fluids, optional equipment and accessories that can be safely supported by a combination of all axles.
UVW (Unloaded Vehicle Weight)* – is the typical weight of the unit as manufactured at the factory. It includes all weight at the unit’s axle(s) and tongue or pin and LP Gas. The UVW does not include cargo, fresh potable water, additional optional equipment or dealer installed accessories.
*Estimated Average based on standard build optional equipment.
CCC (Cargo Carrying Capacity) ** – is the amount of weight available for fresh potable water, cargo, additional optional equipment and accessories. CCC is equal to GVWR minus UVW. Available CCC should accommodate fresh potable water (8.3 lbs per gallon). Before filling the fresh water tank, empty the black and gray tanks to provide for more cargo capacity.
**Estimated Average based on standard build optional equipment.
Each Forest River RV is weighed at the manufacturing facility prior to shipping. A label identifying the unloaded vehicle weight of the actual unit and the cargo carrying capacity is applied to every Forest River RV prior to leaving our facilities.
The load capacity of your unit is designated by weight, not by volume, so you cannot necessarily use all available space when loading your unit.
Actual towing capacity is dependent upon your particular loading and towing circumstances, which includes the GVWR, GAWR and GCWR as well as adequate trailer brakes. Please refer to the Operator's Manual of your vehicle for further towing information.
Note: Specifications are subject to change without notice.
- Black Tank Flush
- Battery Disconnect Switch
- Siphon 360 Holding Tank Roof Vent
- Heavy Duty Standard Tongue Jack
- Outside Utility Shower w/ Hands Free Holder
- (2)20 lb. LP Tanks
- BlackABS LP Bottle Cover
- LP Quick Connect
- Flush Mount Baggage Doors w/Radius Corners
- Stabilizer Jacks
- G20 Tinted Privacy Windows
- Premium JBL Exterior Speakers(s)
- Friction Hinge Door
- Radius Cornered Fiberglass Entry Door
- Exterior 110V G.F.C.I Protected Receptacle
- Exterior RG-6 Coax Cabling and Satellite Prep
- Exterior TV Hookup
- Rain Gutters with Drip Spouts
- Flip Down Steel Steps
- XL Swing Arm Entry Assist Handle (Main Entrance Only)
- Residential Sliding Glass Patio Door
- Large Front Bay Windows
- Pets - "Leash Link" Quick Hookup D-Ring
- Universal Solar Prep w/Roof & Chg. Contoller Connections & Wiring
- One Control Smart RV Tech Monitor Panel (uses LCI OneControl - App)
- RV-LINK 4G LTE Remote Connect, WiFi, Booster, and Extender
- Premium Audio JBL Aura Cube Multi-Zone Function Media Center
- Premium JBL Interior Speaker(s)
- 18 Cu. Ft. Residential Refrigerator
- Seamless Thermofoil Countertops Throughout
- Under-mount Farm Style Sink
- Residential Kitchen Faucet w/Pull Down Sprayer
- Flush Counter Split Kitchen Sink Covers
- 3 Burner SST Range w/Flush Glass Top & LED Accent's (21" Oven)
- Slim Line Range Hood
- SST Microwave W/Glass Turn Table
- Congoleum Woodplank Linoleum Flooring
- 4000 Lumin LED Interior Lighting
- Directional Master Bed Reading Lights
- Residential Tri-Fold Sofa
- Designer Wall Light Main Slide Room
- Hard Valance Window Treatments
- Pedestal Thermofoil Dinette Table
- Under Bench Dinette Storage (Per Floorplan)
- Easy Access Booth Dinette Storage Doors
- 12V 14" Living Room Power Vent Fan
- 12V 14" Bathroom Power Vent Fan
- Marine Toilet with Foot Flush
- ABS Tub/Shower Surround w/Shelves
- Skylight Above Tub/Shower
- Glass Step-In Shower w/ABS Surround (Per Floorplan)
- Medicine Wall Cabinet with Mirror
- Bedroom Surface Mounts USB Ports (Each Night Stand)
- Kitchen USB's & Outlets
- Solid Master Bedroom Door(s) (Per Floorplan)
- Mirrored Wardrobes in Master Bedroom
- Master Bedroom Overhead Cabinets
- Underbed Storage w/Separation from Outside Front Storage
- Designer Fitted Master Bed Sheet
- Full Lino in Slide-Outs and Bedrooms (Carpetless)
- 39" TV
- Swing Arm TV Bracket
- Fireplace w/Electric Heater in the Living Room
- Ceiling Fans in Living Room and Master Bedroom w/Wall Switch
- Premium Serta Mattress
- Washer/Dryer Prep (39MKTS, 39RLTS)
Construction & Equipment Features
- Cambered Structural Steel I-Beam Frame
- New Road Defense Chassis Powder Coating
- Full Length Frame Outriggers
- 5/8" Tongue & Groove Plywood Floor Decking
- 2"x3" Floor Joists on Approximately 12" Centers
- 5" Floor To Frame Steel Lag Bolts
- Darco Subfloor Protective Wrap/Enclosure
- Seamless Alpha Roof Membrane with Lifetime Warranty
- Cross-Braced Engineered Roof Trusses w/5" Crown
- 3/8" Fully Decked Walk-On Roof
- Screwed Cabinet Construction w/Pocket Bored Lumber Core Stiles
- Hardwood Cabinet Doors
- 5/8" Plywood Under Bed & Dinette Base
- 84" Interior Height (7')
- Easy-Trac Rack and Pinion Through Frame Main Slide-Out(s)
- Schwintek Slide Out (Bed)
- R-7 Fiberglass Insulation Throughout
- 10 Gal. Gas/Electric DSI Water Heater
- Water Heater By-Pass Winterization Kit
- 12V Demand Water Pump
- Premium Exterior Graphics Package
- Platinum .024" Aluminum Exterior w/.030 Skirt Metal
- Polished HD Aluminum Fender Skirts
- Dexter EZ Lube Axles w/Leaf Spring Suspension
- Self Adjusting Brakes
- Roto-Cast Holding Tanks
- Bumper w/ Drain Hose Carrier and End Caps
- 35,000 BTU Auto-Ignition Furnace w/Wall Thermostat
- Residential In-Floor Ducted Heat
- 15,000 BTU Fully Ducted A/C
- 50 AMP Elect. Service
- Upgraded Aluminum Wheels
- Magnetic Hands Free Baggage Door Latches
- Smoke Alarm
- LP/CO Gas Detector
- Fire Extinguisher
- Fire Escape Windows
- Entrance Door Window
- Dead-Bolt Lock on Entry Door
- SafeRide RV Motor Club (1 YR Roadside Assistance)
- Enclosed, Fully Sealed Currugated Underbelly
- 2nd 13,500 BTU A/C
- Peak Performance Solar Package - 30A Controller w/ 200W Panel
- Free Standing Table w/4 Chairs (N/A U-Dinette Floorplans)
- GE Washer/Dryer Combo Unit (Per Floorplan)
- Electric Awning w/Multicolor LED Strip & Remote
- Spare Tire w/ Tire Carrier
- Non-Self Contained w/Porcelain Toilet
- Detachable Hitch
- CSA Standards
