Catalina Trail Blazer Toy Haulers

Introducing the newest segment to the Catalina line-up, the Trail Blazer toy hauler. The Trail Blazer is a versatile new line that gives RV users the functionality of a toy hauler, with the luxury and amenities of a travel trailer. Designed to provide an abundant number of uses that fit the RV lifestyle, the Trail Blazer is assembled with a focus on quality and functionality. Steel-to-steel tie-downs and tongue-and-groove plywood floors secure the garage, while a full kitchen, entertainment center, bed and bathroom provide exceptional living quarters. An optional party deck transforms the loading ramp into usable space that turns this unit into the ultimate weekend warrior! Offered in two floorplans, the 19TH and 26TH provide campers with extreme functionality without lacking any amenities.

* Due to the current environment our features and options are subject to change due to material availability


RV Pro Best New Model 2021Care Camps, fighting cancer and making memoriesLink opens in a new tab/window

Floorplans

Print

Trail Blazer Floorplans


Specifications

Print

Floorplan: 26TH : Trail Blazer Floorplans 27THS : Trail Blazer Floorplans 28THS : Trail Blazer Floorplans 29THS : Trail Blazer Floorplans 30THS : Trail Blazer Floorplans
Hitch Weight:957 lb.1,314 lb.1,126 lb.1,206 lb.1,382 lb.
GVWR:7,900 lb.11,514 lb.10,500 lb.9,800 lb.10,500 lb.
UVW:5,486 lb.7,471 lb.7,226 lb.7,082 lb.7,600 lb.
CCC:2,414 lb.4,043 lb.3,274 lb.2,718 lb.2,900 lb.
Exterior Length:30' 0"33' 10"33' 10"35' 8"36' 1"
Exterior Height:10' 7"11' 10"12' 0"11' 1"11' 10"
Exterior Width:96"96"96"96"96"
Fresh Water:44.00 gal.44.00 gal.98.00 gal.44.00 gal.98.00 gal.
Gray Water:40.00 gal.70.00 gal.40.00 gal.40.00 gal.70.00 gal.
Black Water:30.00 gal.30.00 gal.30.00 gal.30.00 gal.30.00 gal.
Awning Size:15'21'18'15'18'

GVWR (Gross Vehicle Weight Rating) – is the maximum permissible weight of the unit when fully loaded. It includes all weights, inclusive of all fluids, cargo, optional equipment and accessories. For safety and product performance do NOT exceed the GVWR.

GAWR (Gross Axle Weight Rating) – is the maximum permissible weight, including cargo, fluids, optional equipment and accessories that can be safely supported by a combination of all axles.

UVW (Unloaded Vehicle Weight)*- is the typical weight of the unit as manufactured at the factory. It includes all weight at the unit’s axle(s) and tongue or pin and LP Gas. The UVW does not include cargo, fresh potable water, additional optional equipment or dealer installed accessories.
*Estimated Average based on standard build optional equipment.

CCC (Cargo Carrying Capacity)** - is the amount of weight available for fresh potable water, cargo, additional optional equipment and accessories. CCC is equal to GVWR minus UVW. Available CCC should accommodate fresh potable water (8.3 lbs per gallon). Before filling the fresh water tank, empty the black and gray tanks to provide for more cargo capacity.
**Estimated Average based on standard build optional equipment.

Each Coachmen RV is weighed at the manufacturing facility prior to shipping. A label identifying the unloaded vehicle weight of the actual unit and the cargo carrying capacity is applied to every Coachmen RV prior to leaving our facilities.

The load capacity of your unit is designated by weight, not by volume, so you cannot necessarily use all available space when loading your unit.

Features & Options

Print

  • Electric Awning w/Multicolor LED Strip & Remote
  • Black Tank Flush
  • Battery Disconnect Switch
  • Siphon 360 Holding Tank Roof Vent
  • Electric Tongue Jack
  • Outside Utility Shower w/ Hands Free Holder
  • (2)20 lb. LP Tanks
  • BlackABS LP Bottle Cover
  • LP Quick Connect
  • Flush Mount Baggage Doors w/Radius Corners
  • Diamond Plate Rock Guard
  • Stabilizer Jacks
  • G20 Tinted Privacy Windows
  • Premium JBL Exterior Speakers(s)
  • Friction Hinge Door
  • Radius Cornered Fiberglass Entry Door
  • Exterior 110V G.F.C.I Protected Receptacle
  • Exterior RG-6 Coax Cabling and Satellite Prep
  • Exterior TV Hookup
  • Rain Gutters with Drip Spouts
  • SolidStep Entrance Steps IPO Flip-Down Steps (Main Entrance Only)
  • XL Swing Arm Entry Assist Handle (Main Entrance Only)
  • Rear View Camera Prep
  • 15' Toy Loc Cable
  • Lockable Ramp Door Latches
  • Rear LED Loading Lights
  • Pets - "Leash Link" Quick Hookup D-Ring
  • Universal Solar Prep w/Roof & Chg. Contoller Connections & Wiring
  • One Control Smart RV Tech Monitor Panel (uses LCI OneControl - App)
  • RV-LINK 4G LTE Remote Connect, WiFi, Booster, and Extender
  • Premium Audio JBL Aura Cube Multi-Zone Function Media Center
  • Premium JBL Interior Speaker(s)
  • 10 Cu. Ft. 12V Refrigerator
  • Seamless Thermofoil Countertops Throughout
  • Under-mount Farm Style Sink
  • Residential Kitchen Faucet w/Pull Down Sprayer
  • Flush Counter Split Kitchen Sink Covers
  • 3 Burner SST Range w/Flush Glass Top & LED Accent's
  • Slim Line Range Hood
  • SST Microwave W/Glass Turn Table
  • Congoleum Woodplank Linoleum Flooring
  • 4000 Lumin LED Interior Lighting
  • Hard Valance Window Treatments
  • Pedestal Thermofoil Dinette Table (29THS)
  • Portable Dinette Table
  • Under Bench Dinette Storage (29THS)
  • Easy Access Booth Dinette Storage Doors (29THS)
  • 12V 14" Living Room Power Vent Fan
  • 12V 14" Bathroom Power Vent Fan
  • Marine Toilet with Foot Flush
  • ABS Tub/Shower Surround w/Shelves
  • Skylight Above Tub/Shower
  • Glass Step-In Shower w/ABS Surround (Per Floorplan)
  • Medicine Wall Cabinet with Mirror
  • Bedroom Surface Mounts USB Ports (Each Night Stand)
  • Kitchen USB's & Outlets
  • Solid Master Bedroom Door(s) (Per Floorplan)
  • Full Length Night Stands (N/A Bed Slide-Outs)
  • Mirrored Wardrobes in Master Bedroom
  • Master Bedroom Overhead Cabinets
  • Underbed Storage w/Separation from Outside Front Storage
  • Designer Fitted Master Bed Sheet
  • Full Lino in Slide-Outs and Bedrooms (Carpetless)
  • Raised Ceiling w/Cargo Area HappiJac Bed Lift (28THS, 30THS)
  • 500 lb. Tie Down - 10-12 Ties per Floorplan
  • Rear Loading Cargo Door w/3,000 lb. Capacity
  • Black Out Screen Wall w/Zip Walk-Thru & Windows
  • Rock Run Reinforced Interior Drive On Wheel Wells (26TH Only)
  • Cambered Structural Steel I-Beam Frame
  • New Road Defense Chassis Powder Coating
  • Full Length Frame Outriggers
  • 5/8" Tongue & Groove Plywood Floor Decking
  • 2"x3" Floor Joists on Approximately 12" Centers
  • 5" Floor To Frame Steel Lag Bolts
  • Enclosed, Fully Sealed Corrugated Underbelly
  • Darco Subfloor Protective Wrap/Enclosure
  • Seamless Alpha Roof Membrane with Lifetime Warranty
  • Cross-Braced Engineered Roof Trusses w/5" Crown
  • 3/8" Fully Decked Walk-On Roof
  • Screwed Cabinet Construction w/Pocket Bored Lumber Core Stiles
  • Hardwood Cabinet Doors
  • 5/8" Plywood Under Bed & Dinette Base
  • 81" Interior Height (6' 9")
  • Easy-Trac Rack and Pinion Through Frame Main Slide-Out(s)
  • Schwintek Slide Out
  • R-7 Fiberglass Insulation Throughout
  • 6 Gal. Gas/Electric DSI Water Heater
  • Water Heater By-Pass Winterization Kit
  • 12V Demand Water Pump
  • Premium Exterior Graphics Package
  • Upgraded Front Graphics Design
  • Platinum .024" Aluminum Exterior w/.030 Skirt Metal
  • Smooth HD Aluminum Radius Front
  • Polished HD Aluminum Fender Skirts
  • Spare Tire, Carrier, and Cover
  • Dexter EZ Lube Axles w/Leaf Spring Suspension
  • Self Adjusting Brakes
  • Roto-Cast Holding Tanks
  • Bumper w/ Drain Hose Carrier and End Caps
  • 30,000 BTU Auto-Ignition Furnace w/Wall Thermostat
  • Flex Ducted Cabinet/Wall Heat
  • 13,500 BTU Fully Ducted A/C
  • 30 Amp Elect. Service w/ 100v 45-Amp Power Covt.
  • Upgraded Aluminum Wheels
  • Magnetic Hands Free Baggage Door Latches
  • Smoke Alarm
  • LP/CO Gas Detector
  • Fire Extinguisher
  • Fire Escape Windows
  • Entrance Door Window
  • Dead-Bolt Lock on Entry Door
  • SafeRide RV Motor Club (1 YR Roadside Assistance)
  • 7 Cu. Ft. LP Gas/Electric RV Refrigerator w/Reversable Door Inserts
  • (2) Pushback Recliners (26TH, 28THS, 30THS Only)
  • 15,000 BTU Ducted A/C IPO 13.5 A/C
  • 50 Amp Service w/ 2nd 13.5 A/C (N/A 26TH)
  • 50 Amp Service w/2nd A/C Prep (N/A 26TH)
  • Peak Performance Solar Package - 30A Controller w/ 200W Panel
  • Tri-Fold Hide A Bed Sofa (29THS)
  • Steel Fold-Down Steps ipo SolidStep Entrance Steps
  • Ramp Door Patio & Railing System
  • Fuel Station w/ 30 Gallon Fuel Tank (N/A 26TH)
  • CSA Standards
